Oven slides
Precision in high temperatures.
Our oven slides are designed for extreme temperatures and high loads. They ensure stable, smooth removal of trays and grates – permanently reliable, even in intensive, continuous use.
Safety and control in a hot work environment.
The sturdy slide and defined positioning enable safe and comfortable food handling.
Accuracy
An accurately defined locking position ensures that the oven shelf reliably remains in position – even when heavily loaded with heavy trays or roasting tins. The pull-out offers a tilt-proof grip and makes it easy to comfortably work on the open oven. At the same time, the locking function prevents the slide from moving back unintentionally. The result is a stable, safe working position and noticeably more pleasant handling in daily use.
Flexibility
Choice of fixed or flexible system connection. For the fixed connection, the slide is welded to the oven; the flexible version uses a clip for attachment. This ensures maximum flexibility when cleaning, installing and removing the slide.
Benefits
There are many good reasons for GRASS slides.
Easy to clean without the need for tools.
In the clip version, the slides can be removed from the oven without the need for tools, which makes cleaning easy.
High levels of stability thanks to defined locking position.
Individual system connection.
Depending on requirements, the slide connection can be fixed or flexible. The modular system makes it easier to install and remove the slide.
Safe and convenient to use.
Our sliding systems grant safe access to the baking tray outside the hot oven.
Highly temperature-resistant, stainless steel platform.
The stainless steel slide can withstand temperature peaks of up to 330°C.
Flexible integration into different appliance concepts.
One platform for many applications.
Various oven platforms can be reliably implemented with our highly temperature-resistant sliding systems. The system concept enables flexible integration into different appliance categories and supports scalable product strategies. At the same time, the sophisticated design ensures easy installation and optimised production processes.
Technology
Technology
Detailed product specifications.
Material
100% stainless steel
Load capacity
Up to 15 kg
Test cycles
10.000
Corrosion-resistant
24 h salt spray test in accordance with DIN EN ISO 9227 | 240 h condensation water test in accordance with DIN EN ISO 6270
Temperature range
300°C constant temperature | 330°C temperature peaks
Lubrication
H1-approved lubricant (safe for food)
RoHS
RoHS-compliant
Dimensions
Width: 10.5 mm | Height: 22.5 mm
